Welded Mesh Decorative Fence – Elegance Meets Security
Welded Mesh Decorative Fence
The Welded Mesh Decorative Fence unites aesthetic appeal with protective properties to provide permanent decorative solutions for all properties. Aesthetic value and security protections define this fence which displays elaborate patterns along with a strong welded mesh design construction. The Welded Mesh Decorative Fence serves both safety and design needs while being suitable for residential, commercial and public areas. The fence uses weather-proof materials and optional customization that makes it both stunning and reliable for different settings.

Key Features of Welded Mesh Decorative Fence
Mesh Size | Variable according to clients' request |
Wire Diameter | 4mm, 5mm or 6mm via Vertical and Horizontal Wires |
Material | Galvanized steel |
Post Dimensions |
50 x 50 mm (up to 1.5m high) 60 x 60 mm SHS (up to 3000 mm) 50 x 100 mm RHS (up to 6000 mm) |
Standard Panel Width | 2500 mm, Customizable |
Panel Heights | 950 mm, 1450 mm, 1950 mm (stackable up to 6000 mm) |
Tensile Strength | Min. 500 N/mm² |
Welding Strength | 50% of total tensile strength in accordance with EN 10223-7 |
Post Centers | 2500 mm, Customizable |
Colors | Black RAL 9005, Green RAL 6005, Customizable |
Mesh Size |
Variable according to clients' request |
Wire Diameter |
4mm, 5mm or 6mm via Vertical and Horizontal Wires |
Material |
Galvanized steel |
Post Dimensions |
50 x 50 mm (up to 1.5m high) 60 x 60 mm SHS (up to 3000 mm) 50 x 100 mm RHS (up to 6000 mm) |
Standard Panel Width |
2500 mm, Customizable |
Panel Heights |
950 mm, 1450 mm, 1950 mm (stackable up to 6000 mm) |
Tensile Strength |
Min. 500 N/mm² |
Welding Strength |
50% of total tensile strength in accordance with EN 10223-7 |
Post Centers |
2500 mm, Customizable |
Colors |
Black RAL 9005, Green RAL 6005, Customizable |
Key Components of Welded Mesh Decorative Fence

Posts
The posts come in two profiles which are 60x60mm and 40x80mm to face intense force while providing versatile usage. The system allows installation using in-ground mounting or base attachment or wall installation methods and other various mounting methods.
Over-length set in the ground
Base plated for bolting onto concrete
Cranked for wall mounting
Covered with a plastic cap on top
Extended with a 45-degree crank on top
Extended with a double (Y) crank on top
Panels
The panels' 2490mm width equipped with 4mm wires produce both security and visual design excellence. The security barrier offers customizable heights from 1130mm to 1960mm and provides dimensions of 2490mm width with 4mm wires present.
Standard Panel Width : 2500 mm
Panel Heights 950 mm: 1450 mm, 1950 mm (stackable up to 6000 mm)
Panel Widths: 2500 mm


Fittings
The fence's durability depends on using robust 50x5mm flat bar clamps for attaching panels to create a solid structure.
Gates
Select from numerous gate design options that range from manual to automate with styles that align with different fencing preferences

Finishing Options
Hot-Dip Galvanizing
Hot-dip galvanization according to BS EN ISO 1461 must be applied to all steel components for providing enhanced corrosion resistance and prolonged service duration
Powder Coating
The implementation of BS EN 13438 hot-dip galvanizing and high-quality powder coating process creates durable components with improved appearance according to standard specifications
Marine-Grade Protection
Surface applications of specialized marine-grade coating systems are mandatory on all installations situated within 500 meters of saltwater or estuarine environments to counter salt-induced corrosion.
PVC Coating
The decorative welded mesh fence coating from PVC delivers durable weatherproof protection alongside fashionable finishing. The smooth coating makes this material appear attractive while simultaneously delivering durable safety for both residential and commercial buildings.
Advantages of Our Customizable Installation
Customizable Mesh Design | Mesh design flexibility enables customers to choose their preferred opening sizes for achieving custom appearances. |
Strong & Durable Wires | Available in 4mm, 5mm, and 6mm for enhanced security and longevity. |
Elegant 2D Profile | This feature delivers a smooth contemporary design which fits multiple outdoor environments. |
Ideal for Large Areas | This solution provides optimum security through aesthetic visuals which suit residential and commercial and public areas. |
Customizable Mesh Design |
Mesh design flexibility enables customers to choose their preferred opening sizes for achieving custom appearances. |
Strong & Durable Wires |
Available in 4mm, 5mm, and 6mm for enhanced security and longevity. |
Elegant 2D Profile |
This feature delivers a smooth contemporary design which fits multiple outdoor environments. |
Ideal for Large Areas |
This solution provides optimum security through aesthetic visuals which suit residential and commercial and public areas. |
Applications of Welded Mesh Decorative Fence
Customization and Installation
The Hitech experience provides fencing services with complete ease and without complications to customers. Expert personnel from our team work through the whole process from design to installation while creating customized Welded Mesh Decorative Fence solutions for each client's needs. We assist new customers through every step of their fencing project because setting up fencing requires expertise which we provide.
End-to-End Service – We handle everything from custom design and material selection to professional installation.
Expert Guidance – Our fencing specialists provide advice, site evaluation, and technical support.
Precision Installation – Whether for residential, commercial, or large-scale projects, we ensure a flawless setup.
Hassle-Free Experience – We take care of the hard work, so you can enjoy immediate security and aesthetic appeal.
