Spike Fence: High Security Perimeter
Spike Fence | Deter Unauthorized Access
Spike fences are constructed to provide added security and deter illicit access to your home or property. It effectively prevents intrusion with its pointed spikes and imposing look. Hitech offers a premier security solution with its anti-climb fence spikes, especially for sensitive areas, and stringent protection. This fence is 3000mm tall, featuring two vertical pales fastened with horizontal rails for your safety.
Palisade Fencing | Key Features
Robust, secure, and aesthetically pleasing fencing designed to meet international standards.
🧗 Anti-Climb Protection
Prevents intruders from climbing.
📘 Standards Compliant
Aligns with BS EN 1722-12 standards.
📏 Safe Spacing
Spacing between the vertical pales complies with building guidelines.
🧱 Post Options
Choose your post options: base plated, over length, or cranked for appropriate installation.
🔧 Custom Tops
Post tops customized for barbed wire, razor wire, electric fencing, or CCTV camera mounting.
🏞️ Sloped Terrain Ready
Fixate sloping terrains with racked or stepped panels.
🧩 Flexible Layout
Adjustable to any space.
🏗️ Durable & Aesthetic
A durable fence that is applicable to any security solution without compromising the aesthetics.
Spike Fence | Components
Posts
Post Options: Our fence spikes posts are engineered from a rectangular hallow section of 60x60 mm coupled with 2 mm of thickness. It is fastened to a small pale and a welded spike of 10 mm. You can adjust the post height with installation.
Installation Options
- Get extended length to fixate it in the ground.
- Base plated for concrete anchoring
- Cranked to accommodate wall mounting.
Panels:
- The fencing panels are 3000 mm in width and composed of vertical square hollow section pales (25x2mm) tightened by two 60x30x2mm horizontal rails (three for heights reaching 3000mm).
- Optimal positioning includes a lower rail set 150mm above ground and an upper rail positioned 175mm below the pale top.
- Pales are spaced 140mm apart with a 122mm post-to-pale center distance.
- Each pale features a 10mm diameter bar welded at a 45-degree angle towards the ground for enhanced security.
Fittings
- All joints between pales, rails, panels, and posts are welded to ensure a secure, tamper-resistant connection, surpassing traditional nut and bolt assemblies.
- Post-installation options include ground embedding or securement with a 150x150mm base plate of robust 10mm thickness, guaranteeing enduring strength and resilience.
Gates
Compatible gates are available in single or double leaf, swing or sliding configurations, manual or automatic operation, tailored to match the fencing system's robust security standards.
Ornamental Fence: Dimensions
| Code | Height | Pales | Post Size | Post Center | Set in Concrete | Base Plated | Horizontal Rail |
|---|---|---|---|---|---|---|---|
| HDE 225 | 2.25 | 25mm squire | 60x60x2x3050mm | 3.0 m Center | 250x250x800 | 350x300x430 | 60x30x2mm |
| HDE 250 | 2.50 | 32mm squire | 60x60x2x3300mm | 3.0 m Center | 250x250x800 | 350x300x430 | 60x30x2mm |
| HDE 300 | 3.00 | 32mm squire | 60x60x2x3800mm | 3.0 m Center | 300x250x800 | 350x300x610 | 60x30x2mm |
| Height | 2.25 |
| Pales | 25mm squire |
| Post Size | 60x60x2x3050mm |
| Post Center | 3.0 m Center |
| Set in Concrete | 250x250x800 |
| Base Plated | 350x300x430 |
| Horizontal Rail | 60x30x2mm |
| Height | 2.50 |
| Pales | 32mm squire |
| Post Size | 60x60x2x3300mm |
| Post Center | 3.0 m Center |
| Set in Concrete | 250x250x800 |
| Base Plated | 350x300x430 |
| Horizontal Rail | 60x30x2mm |
| Height | 3.00 |
| Pales | 32mm squire |
| Post Size | 60x60x2x3800mm |
| Post Center | 3.0 m Center |
| Set in Concrete | 300x250x800 |
| Base Plated | 350x300x610 |
| Horizontal Rail | 60x30x2mm |
Finishing Variations
Hot-Dip Galvanizing
To ensure corrosion and extended service life, all the steel essentials of the fence should be hot galvanized in compliance with BS EN ISO 1461
Powder Coating
After hot dip galvanizing, the components are passed through high-coated powder BS EN 13438 to enhance durability and aesthetic finish
Marine-Grade Protection
To withstand salt-induced corrosion in installations within 500 meters of saltwater, a special marine-grade coating is applied to provide lasting resistance
PVC Coating
The PVC-coated fence Secure 476 Double provides secure cover with a long-lasting weatherproof finish. It extends product lifespan by resisting corrosion
Applications of Palisade Fencing System
Installation Excellence
At HITECH Fencing, we fully support you throughout your fencing project from start to finish. Not only do we custom design and manufacture mesh fencing tailored to your specific needs, but we also provide professional installation services. Our experts are committed to guiding you through every step of the installation process, whether for large or small projects. With our help, you can quickly benefit from secure and reliable fencing, ensuring your complete satisfaction and safety.
