Decorative Fence: Hitech's Elegant Security Solution​


Decorative Fence

Discover HiTech’s Decorative Fence, the perfect fusion of elegance and security, designed to enhance any environment without compromising on safety. Whether it's for a residential area, park, or commercial property, our fences combine visual appeal with robust protection, tailored to meet both aesthetic and functional needs.

Contact Us

Decorative Fence

Features

  • Anti-climb design.
  • Various mounting options including wall-mounted, inset, and free-standing.
  • Post tops can be customized for barbed wire, razor wire, fence spikes, electric fence, or adapted to mount CCTV cameras.
  • Conforms to BS EN 1722-9.
  • Custom designs available to meet specific security and aesthetic requirements.
  • Pale spacing adheres to Building Regulations for anti-entrapment.
  • Finials can be added to pales for decorative purposes.
  • Panels can be raked or stepped to accommodate sloping ground.
  • Seamless and concealed rail-to-post fixing for a clean appearance.
  • Unlimited color options to match any setting or preference.


System Overview: Posts, Panels, and Fittings


Decorative Fence posts

Posts

Crafted from strong 60x60 mm rectangular hollow sections with a 3 mm thickness, the posts offer a post-to-post spacing of 3000 mm center-to-center. Adjustable in height, the posts cater to various installation preferences:

  • Over-length for setting in the ground.
  • Base plated for bolting onto concrete.
  • Cranked for wall mounting




Panels:

Spanning 3000 mm between posts, each panel features pales of 25 mm diameter (up to 2000 mm height) or 32 mm diameter for taller fences. The pales, made from CHR round pipes with 2 mm thickness, pass through 60x30x2 mm horizontal RHS rails. The rails are positioned for maximum strength, with the bottom rail 150 mm above the ground and the top rail 175 mm from the top pale position. Pales are spaced 140 mm center-to-center, with a 122 mm distance between the post and panel. Pale tops are cut at a 45-degree angle to enhance anti-climbing security.


Decorative Fence gates
Decorative Fence fitting

Fittings

Connections between pales and rails, as well as panels and posts, are exclusively welded, avoiding traditional nut-and-bolt assemblies. This ensures a secure, tamper-resistant connection. For post installation, choose between ground placement or a 150x150 mm base plate with a 10 mm thickness.

Gates

Matching gates are available in single or double leaf, swing, sliding, and tracked configurations, with options for manual or automatic operation.

Decorative Fence gates

Specifications & Dimensions

Item Code

Fence Height

Pale Height

Pale Section

Post Size

Horiz. Rail

HIPLS100

1.00m

9.50m

2mm W / 3mm D

102x 44mm

50x50x5mm

HIPLS150

1.50m

1.45m

2mm W / 3mm D

102x 44mm

50x50x5mm

HIPLS200

2.00m

1.95m

2mm W / 3mm D

102x 44mm

50x50x5mm

HIPLS250

2.50m

2.50m

2mm W / 3mm D

102x 44mm

50x50x5mm

HIPLS275

2.75m

2.70m

2mm W / 3mm D

127x 76mm

50x50x5mm

HIPLS300

3.00m

2.90m

2mm W / 3mm D

127x 76mm

50x50x5mm


Standard Colors

Black

RAL 9005

Green

RAL 6005

Brown

RAL 8017

Grey

RAL 7012

Custom

custom colors are available upon request.

Finishing Options

Hot-Dip Galvanizing

All steel components shall be hot-dip galvanized in accordance with BS EN ISO 1461 to ensure superior corrosion protection and extended service life.

Powder Coating

For enhanced durability and aesthetic finish, components shall comply with BS EN 13438, involving hot-dip galvanizing followed by a high-quality powder coating process.

Marine-Grade Protection

For installations within 500 meters of saltwater or estuaries, a specialized marine-grade coating system shall be applied to provide robust resistance against salt-induced corrosion.

Applications of Our Decorative Fences


Installation and Maintenance

At Hitech Fencing, we back our products with comprehensive support from the initial consultation through to installation. Our team of experts ensures that every fencing solution is installed efficiently and with the highest level of craftsmanship to meet your satisfaction and safety standards.
