Welded Mesh Fence 2D868 – Robust and Reliable Security Fencing
HiWeld 2D868™
The HiWeld 2D868 TM, a high-performance double wire mesh fencing system that combines unmatched strength and aesthetics. Designed for demanding commercial environments, this fencing system provides a formidable barrier against intruders and vandals, making it an ideal choice for large-scale security applications.
Available Types
HiWeld 2D868TM fencing system comprises three major elements
Posts
Posts
HiWeld 2D868TM is designed to secure properties of varying scales, with its name inspired by its hollow steel posts. These posts come in measurements of 40x40mm, 60x60mm, or 50x100mm, depending on the fence's height, providing the necessary strength to withstand pressure and force. The posts determine the fence's length and offer several mounting options:
- Over-length set in the ground
- Base plated for bolting onto concrete
- Cranked for wall mounting
- Covered with a plastic cap on top
- Extended with a 45-degree crank on top
- Extended with a double (Y) crank on top
Panels:
The mesh between the posts is known as a panel. These mesh panels feature double horizontal wires of 8mm diameter and single vertical wires of 8mm diameter with a flat profile. The wires are welded at junctions, forming a rectangular opening of 50x200mm, and are treated with a galvanized zinc alloy for enhanced durability. The standard panel heights are 950mm, 1450mm, and 1950mm, and can be stacked to create a fence up to 6000mm high.
To enhance security and prevent climbing, options include:
- 30mm projecting spikes
- 3 or 6 barbed wires
- 3 or 6 barbed wires with a concertina role
The tensile strength of the wires is a minimum of 500 N/mm², with the welding strength at least 50% of the total tensile strength of the wire, in compliance with EN 10223-7.
Fittings
The system uses rigid 40x50mm metal clips or 50x5mm flat bars along the full length of the post to secure the welded steel mesh panels. These fittings are bolted every 400mm using 8mm diameter round head bolts.
Gates
Matching single leaf and double leaf gates are available for the HiWeld 2D868TM fencing system. These gates come with a variety of opening mechanisms and can be manually or automatically operated.
Features
- Mesh apertures of 200x50mm
- Anti-cut double wire mesh panels
- 50mm vertical apertures
- Full-length clamp bar
- Sheardrive fixings
- Anti-climb design
- Multiple height options (up to 6m)
- Full range of RAL colors available
- Customizable posts for barbed wire, razor wire, or Rota Spike
- Fixed through base plates, wall fixing plates, or cranked posts
- Flat profile mesh panels with double 8mm horizontal wires and 6mm vertical wires
- Adjustable for sloping ground
- Privacy screen compatibility for enhanced security
- Stackable panels for increased height
- Heavy welded mesh panels for added rigidity
Finishing Options
Standard Finish
Adapt these three columns to fit your design need. To duplicate, delete or move columns, select the column and use the top icons to perform your action.
Powder Coated Finish
Hot-dip galvanized and powder-coated as per BS EN 13438.
Marine Coat
Additional protective layer for installations within 500 meters of saltwater or estuaries.
Feature & Specification
Feature |
Specification |
Panel Heights |
950mm, 1450mm, 1950mm (up to 6000mm stackable)
|
Panel Widths
|
2500mm standard
|
Mesh Size
|
200mm x 50mm openings
|
Wire Diameter
|
Twin 8mm horizontal, 6mm vertical
|
STANDARD COLOURS
|
|
Applications of HiWeld 3D50™
Installation Process
At HITECH Fence, we provide a complete solution from design to installation. Our experts guide you through every stage of the process to ensure your HiWeld 3D50™ fence is perfectly suited to your requirements.
Manufacturing and Design |
Installation Services |
Aftercare |
Why Choose HiTech Fence’s Welded Mesh Fence 2D868?
At HiTech Fence, our dedication extends through every phase of your fencing project. We not only design and manufacture the Welded Mesh Fence 2D868 to meet your specific needs but also provide comprehensive support and installation services. Our experienced team is committed to ensuring your complete satisfaction from start to finish. We tackle every challenge head-on, ensuring that the installation process is smooth and that you quickly benefit from the enhanced security and aesthetics of our reliable fencing solutions
